Konzertgerät 3295 Stereo Nussbaum

Konzertgerät 3295 Stereo; Grundig Radio- (ID = 122722) Radio

Konzertgerät 3295 Stereo; Grundig Radio- (ID = 122723) Radio
Konzertgerät 3295 Stereo; Grundig Radio- (ID = 1310362) Radio Konzertgerät 3295 Stereo; Grundig Radio- (ID = 25504) Radio
Konzertgerät 3295 Stereo; Grundig Radio- (ID = 821031) Radio Konzertgerät 3295 Stereo; Grundig Radio- (ID = 821030) Radio
Konzertgerät 3295 Stereo; Grundig Radio- (ID = 1987258) Radio Konzertgerät 3295 Stereo; Grundig Radio- (ID = 1987259) Radio
Konzertgerät 3295 Stereo; Grundig Radio- (ID = 1987260) Radio Konzertgerät 3295 Stereo; Grundig Radio- (ID = 1987261) Radio
Konzertgerät 3295 Stereo; Grundig Radio- (ID = 1987262) Radio Konzertgerät 3295 Stereo; Grundig Radio- (ID = 1987263) Radio
Use red slider bar for more.
Konzertgerät 3295 Stereo; Grundig Radio- (ID = 1310362) Radio
Grundig Radio-: Konzertgerät 3295 Stereo [Radio] ID = 1310362 800x513
Select picture or schematic to display from thumbnails on the right and click for download.
For model Konzertgerät 3295 Stereo Nussbaum, Grundig (Radio-Vertrieb, RVF, Radiowerke)

Country:  Germany
Manufacturer / Brand:  Grundig (Radio-Vertrieb, RVF, Radiowerke)
alternative name

Grundig Portugal || Grundig USA / Lextronix
Year: 1961/1962 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 7: ECC85 ECH81 EF89 EABC80 EM84 ECC83 ELL80
Main principle Super-Heterodyne (Super in general); ZF/IF 460/10700 kHz
Tuned circuits 6 AM circuit(s)     10 FM circuit(s)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 110; 125; 220 Volt
Loudspeaker 3 Loudspeakers
Power out 5 W (unknown quality)
from Radiomuseum.org Model: Konzertgerät 3295 Stereo [Nussbaum] - Grundig Radio-Vertrieb, RVF,
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 570 x 335 x 220 mm / 22.4 x 13.2 x 8.7 inch
Notes 5-W-Gegentakt-Endstufe in Zweiwegtechnik.
Net weight (2.2 lb = 1 kg) 9.5 kg / 20 lb 14.8 oz (20.925 lb)
Price in first year of sale 395.00 DM
Collectors' prices
External source of data Erb
Source of data HdB d.Rdf-& Ferns-GrH 1961/62
