Musikgerät 2460 Nussbaum

Musikgerät 2460; Grundig Radio- (ID = 462930) Radio
Musikgerät 2460; Grundig Radio- (ID = 589527) Radio Musikgerät 2460; Grundig Radio- (ID = 1097099) Radio
Musikgerät 2460; Grundig Radio- (ID = 877400) Radio Musikgerät 2460; Grundig Radio- (ID = 877401) Radio
Musikgerät 2460; Grundig Radio- (ID = 877402) Radio Musikgerät 2460; Grundig Radio- (ID = 877403) Radio
Musikgerät 2460; Grundig Radio- (ID = 453563) Radio Musikgerät 2460; Grundig Radio- (ID = 1097101) Radio
Use red slider bar for more.
Musikgerät 2460; Grundig Radio- (ID = 589527) Radio
Grundig Radio-: Musikgerät 2460 [Radio] ID = 589527 500x374
Select picture or schematic to display from thumbnails on the right and click for download.
For model Musikgerät 2460 Nussbaum, Grundig (Radio-Vertrieb, RVF, Radiowerke):
.mercadolibre.com

Country:  Germany
Manufacturer / Brand:  Grundig (Radio-Vertrieb, RVF, Radiowerke)
alternative name

Grundig Portugal || Grundig USA / Lextronix
Year: 1963/1964 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: ECC85 ECH81 EF89 EABC80 EM87 EL84
Main principle Superheterodyne (common); ZF/IF 460/10700 kHz
Tuned circuits 6 AM circuit(s)     10 FM circuit(s)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 110; 125; 220 Volt
Loudspeaker 3 Loudspeakers
Power out 4 W (unknown quality)
from Radiomuseum.org Model: Musikgerät 2460 [Nussbaum] - Grundig Radio-Vertrieb, RVF,
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 550 x 310 x 220 mm / 21.7 x 12.2 x 8.7 inch
Notes
Net weight (2.2 lb = 1 kg) 9 kg / 19 lb 13.2 oz (19.824 lb)
Price in first year of sale 384.00 DM
External source of data Erb
Source of data Handbuch VDRG 1963/1964
