Grundig Radio-: Musikschrank 8066 [Radio] ID = 59882 399x319

Select picture or schematic to display from thumbnails on the right and click for download.

For model Musikschrank 8066, Grundig (Radio-Vertrieb, RVF, Radiowerke):
ebay

Country:

Germany

Manufacturer / Brand:

Grundig (Radio-Vertrieb, RVF, Radiowerke)

alternative name

Grundig Portugal || Grundig USA / Lextronix

Year: 1956/1957

Category: Broadcast Receiver - or past WW2 Tuner

Valves / Tubes

9: ECC85 ECH81 EBF89 EC92 EM34 or EM35 ECC83 EAA91 EL95 EL95

Main principle	Superheterodyne (common)
Tuned circuits	8 AM circuit(s) 13 FM circuit(s)
Wave bands	Broadcast, Long Wave, Short Wave plus FM or UHF.
Details	Record Player (perh.Changer)
Power type and voltage	Alternating Current supply (AC) / 110; 125; 160; 220 Volt
Loudspeaker	5 Loudspeakers
Power out
from Radiomuseum.org	Model: Musikschrank 8066 - Grundig Radio-Vertrieb, RVF,
Material	Wooden case
Shape	Console with any shape - in general
Dimensions (WHD)	1170 x 900 x 410 mm / 46.1 x 35.4 x 16.1 inch
Notes	Frequenzbereiche: *UKW 87 bis 100 MHz* *KW 5,9 bis 16 MHz* *MW 510 bis 1620 kHz* *LW 145 bis 350 kHz* Eingebaute UKW-Antenne und Ferritstab-Antenne für MW/LW Eingebaute Lautsprecher: *1 Pdyn Frontlautsprecher* *2 Pdyn Seitenlautsprecher* *2 Hochtonlautsprecher* Leistungsaufnahme: *55 Watt* Plattenspieler: *12 Watt* Trockengleichrichter: B250C100N2 Skalenbeleuchtung: 2 Lämpchen, zylindrisch 7V/0,3A Ferritanzeige: 1 x 6V/0,1A DIN72601 Schrankbeleuchtung: 220 Volt/15 Watt, auswechselbar für andere Spannungen Anschlüsse für: Raumklangstrahler Grundig Fern-Dirigent
Net weight (2.2 lb = 1 kg)	57.5 kg / 126 lb 10.4 oz (126.652 lb)
Price in first year of sale	898.00 DM
External source of data	Erb
Source of data	HdB d.Rdf-& Ferns-GrH 1956/57
Mentioned in	Bedienungsanleitung
