Stereo-Konzertschrank SO1a/1 (SO1a1)

Stereo-Konzertschrank SO1a/1 ; Grundig Radio- (ID = 229010) Radio

Stereo-Konzertschrank SO1a/1 ; Grundig Radio- (ID = 229011) Radio

Stereo-Konzertschrank SO1a/1 ; Grundig Radio- (ID = 1157081) Radio
Stereo-Konzertschrank SO1a/1 ; Grundig Radio- (ID = 1542850) Radio Stereo-Konzertschrank SO1a/1 ; Grundig Radio- (ID = 1542843) Radio
Stereo-Konzertschrank SO1a/1 ; Grundig Radio- (ID = 1542840) Radio Stereo-Konzertschrank SO1a/1 ; Grundig Radio- (ID = 1542837) Radio
Stereo-Konzertschrank SO1a/1 ; Grundig Radio- (ID = 576908) Radio Stereo-Konzertschrank SO1a/1 ; Grundig Radio- (ID = 576909) Radio
Use red slider bar for more.
Stereo-Konzertschrank SO1a/1 ; Grundig Radio- (ID = 1542850) Radio
Grundig Radio-: Stereo-Konzertschrank SO1a/1 [Radio] ID = 1542850 740x492
Select picture or schematic to display from thumbnails on the right and click for download.
For model Stereo-Konzertschrank SO1a/1 (SO1a1), Grundig (Radio-Vertrieb, RVF, Radiowerke)

Country:  Germany
Manufacturer / Brand:  Grundig (Radio-Vertrieb, RVF, Radiowerke)
alternative name

Grundig Portugal || Grundig USA / Lextronix
Year: 1960/1961 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 8: ECC85 ECH81 EF89 EABC80 EM84 ECC83 ELL80 ELL80
Main principle Superheterodyne (common); ZF/IF 460/10700 kHz
Tuned circuits 7 AM circuit(s)     10 FM circuit(s)
Wave bands Broadcast, Long Wave and FM or UHF.
Details Changer (Record changer)
Power type and voltage Alternating Current supply (AC) / 110-220 Volt
Loudspeaker 3 Loudspeakers
Power out
from Radiomuseum.org Model: Stereo-Konzertschrank SO1a/1 - Grundig Radio-Vertrieb, RVF,
Material Wooden case
Shape Console with Push Buttons.
Notes Siehe auch Stereo-Konzertschrank SO1a.
Literature/Schematics (1) -- Original-techn. papers.

Model page created by Josef Pilz. See "Data change" for further contributors.
