• Country
• Germany

• Manufacturer / Brand
• Grundig (Radio-Vertrieb, RVF, Radiowerke); Fürth/Bayern

• Year
• 1966/1967

• Category
• Television Receiver (TV) or Monitor

• Radiomuseum.org ID
• 112490

• • alternative name: Grundig Portugal || Grundig USA / Lextronix

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 10

• Valves / Tubes
• EF85 EL95 PFL200 PCH200 PCL85 PCF802 PL500 PY88 DY86 A59-16W

• Number of Transistors
• 9

• Semiconductors
• AF239 AF139 AF139 AF106 AF106 AF121 BFY39 BF167 BF173 OA91 AA113 AA113 OA90 V40C1 BY100

• Main principle
• Superhet with RF-stage

• Wave bands
• VHF incl. FM and/or UHF (see notes for details)

• Details
• Remote Control (with wire or wireless)

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical

• Material
• Wooden case

• from Radiomuseum.org
• Model: Zauberspiegel T708 - Grundig Radio-Vertrieb, RVF,

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 710 x 520 x 410 mm / 28 x 20.5 x 16.1 inch

• Notes

• Grundig Zauberspiegel T708 ist ein s/w 59 cm Fernsehempfänger,  technisch identisch mit T700.

  Monomat electronic Programmspeicher für 7 VHF/UHF Programme, per Tasten wählbar.

  Twin-panel Bildröhre A59-16W.

  Anschluss für Fernbedienung Fernregler II.

  Der Katalog RFP 1966/67 und teilweise auch Schaltpläne nennen irrtümlich einen Transistor AF173 (letzte Bild-ZF-Stufe), was ein Fehler ist. Tatsächlich wird der Typ BF173 verwendet.

  ---

  Black/white television with VHF and UHF. 23-inch 110° deflection picture tube.

  Monomat Electronic, 7 program preset buttons. 23" widescreen.
  4 different wooden cabinets.

  First price in Italy: 235,000 Italian Lire, 1966.

• Net weight (2.2 lb = 1 kg)
• 34 kg / 74 lb 14.2 oz (74.89 lb)

• Source of data
• Handbuch VDRG 1966/1967

• Mentioned in
• -- Original prospect or advert (La Domenica del Corriere, Italy, 1966)

• Literature/Schematics (1)
• -- Original-techn. papers. (Original Grundig circuit diagram)

• Literature/Schematics (2)
• Handbuch RFP 1966/67 S.38

• Author
• Model page created by Bernd P. Kieck. See "Data change" for further contributors.
