Ö3 IC
Use red slider bar for more.
HEA; Wien: Ö3 IC [Car Radio] ID = 298494 800x600
Select picture or schematic to display from thumbnails on the right and click for download.
|
|
||||
| Year: 1973 | Category: Car Radio, perhaps also + sound player/recorder | ||||
| Semiconductors (the count is only for transistors) | 4: BF200 BF195 BF195 BF273 TBA480 TAA611 |
|---|
| Main principle | Superheterodyne (common); ZF/IF 10700 kHz |
|---|---|
| Wave bands | FM Broadcast Band Only |
| Details | |
| Power type and voltage | Storage Battery for all (e.g. for car radios and amateur radios) / 11-16 Volt |
| Loudspeaker | - This model requires external speaker(s). |
| Power out | |
| from Radiomuseum.org | Model: Ö3 IC - HEA; Wien |
| Material | Plastics (no bakelite or catalin) |
| Dimensions (WHD) | 175 x 40 x 105 mm / 6.9 x 1.6 x 4.1 inch |
| Notes | Gerät wurde im Auftrag des Österreichischen Rundfunks produziert. Sollte eine Art UKW-Volksempfänger für Einkommenschwache werden. |
| Source of data | -- Original-techn. papers. / Radiokatalog Band 2, Ernst Erb |
Model page created by Wolfgang Bauer. See "Data change" for further contributors.
