• Year
  • 1961/1962
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 14955
    • alternative name: Gerätebau Limbach VEB
    • Brand: VEB Elektromechanik Mittweida

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 8
  • Main principle
  • Superheterodyne (common); ZF/IF 460 kHz; 3 AF stage(s)
  • Tuned circuits
  • 8 AM circuit(s)     11 FM circuit(s)
  • Wave bands
  • Broadcast, Long Wave, Short Wave plus FM or UHF.
  • Power type and voltage
  • Alternating Current supply (AC) / 110; 127; 220; 240 Volt
  • Loudspeaker
  • - This model requires external speaker(s).
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: RK2 - Heli Gerätebau, Hempel KG;
  • Shape
  • Tablemodel with Push Buttons.
  • Dimensions (WHD)
  • 640 x 250 x 340 mm / 25.2 x 9.8 x 13.4 inch
  • Notes
  • Empfänger mit getrennter LS-Box in versch. Varianten. Standard-Chassis Heli 3001 (ohne Ferritantenne), als Standgerät = RS2. Ab Ende 1962 8/12 Kreise.
  • Price in first year of sale
  • 650.00 DM
  • External source of data
  • E. Erb 3-907007-36-0
  • Source of data
  • Radiokatalog Band 2, Ernst Erb
  • Literature/Schematics (1)
  • Funkverlag Hein, Service-DVD
  • Picture reference
  • Das Gerät ist im Doppelband "Historische Radios" von Günther Abele abgebildet.
