Melodia

Melodia ; Helvar Suomen (ID = 889035) Radio
Melodia ; Helvar Suomen (ID = 1289485) Radio Melodia ; Helvar Suomen (ID = 1364606) Radio
Melodia ; Helvar Suomen (ID = 1364607) Radio Melodia ; Helvar Suomen (ID = 1364608) Radio
Melodia ; Helvar Suomen (ID = 1364609) Radio Melodia ; Helvar Suomen (ID = 1364610) Radio
Melodia ; Helvar Suomen (ID = 1364611) Radio Melodia ; Helvar Suomen (ID = 1498503) Radio
Use red slider bar for more.
Melodia ; Helvar Suomen (ID = 1289485) Radio
Helvar Suomen: Melodia [Radio] ID = 1289485 922x692
Select picture or schematic to display from thumbnails on the right and click for download.
For model Melodia, Helvar (Suomen Koneliike); Helsinki

Country:  Finland
Manufacturer / Brand:  Helvar (Suomen Koneliike); Helsinki
alternative name

Arma, Helsinki
Year: 1957/1958 ? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: ECC85 ECH81 EF89 EABC80 EM80 EL84
Main principle Superheterodyne (common); ZF/IF 484/10700 kHz; 2 AF stage(s)
Tuned circuits 6 AM circuit(s)     9 FM circuit(s)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details Tape Recorder
Power type and voltage Alternating Current supply (AC) / 110-240 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: Melodia - Helvar Suomen Koneliike;
Material Wooden case
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 560 x 900 x 360 mm / 22 x 35.4 x 14.2 inch
Net weight (2.2 lb = 1 kg) 25 kg / 55 lb 1.1 oz (55.066 lb)
External source of data Jari Aalto
Literature/Schematics (4) -- Schematic

Model page created by Ernst Erb. See "Data change" for further contributors.



All listed radios etc. from Helvar (Suomen Koneliike); Helsinki
Here you find 248 models, 206 with images and 92 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
