For model 260U, Herofon / Herophon (brand of Hede Nielsen):
Image taken from polish online auction portal .allegro.pl. Auction number: 5664410986

Country:  Denmark
Manufacturer / Brand:  Herofon / Herophon (brand of Hede Nielsen)
alternative name

Hede Nielsen's Fabrikker A/S
Year: 1941/1942 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 7: UCH21 UCH21 UCH21 UBL21 UM4 UBL21 UY21
Main principle Superheterodyne (common); ZF/IF 447 kHz; 3 AF stage(s)
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast, Long Wave and more than two Short Wave bands.
Details
Power type and voltage AC/DC-set / 110; 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: 260U - Herofon / Herophon brand of
Material Wooden case
Shape Tablemodel, high profile (upright - NOT Cathedral nor decorative).
Notes

Push-Pull output stage.

Model page created by Tomasz Szczesniak. See "Data change" for further contributors.
