Petite FM-FO-2-RG

Petite FM-FO-2-RG; Herofon / Herophon (ID = 2486408) Radio Petite FM-FO-2-RG; Herofon / Herophon (ID = 2486410) Radio
Petite FM-FO-2-RG; Herofon / Herophon (ID = 2486412) Radio Petite FM-FO-2-RG; Herofon / Herophon (ID = 2486413) Radio
Petite FM-FO-2-RG; Herofon / Herophon (ID = 2486415) Radio Petite FM-FO-2-RG; Herofon / Herophon (ID = 2486416) Radio
Petite FM-FO-2-RG; Herofon / Herophon (ID = 2486417) Radio
Use red slider bar for more.
Petite FM-FO-2-RG; Herofon / Herophon (ID = 2486408) Radio
Herofon / Herophon: Petite FM-FO-2-RG [Radio] ID = 2486408 1189x938
Select picture or schematic to display from thumbnails on the right and click for download.
For model Petite FM-FO-2-RG, Herofon / Herophon (brand of Hede Nielsen):
ebay.de_133332029481, seller rico_3d

Country:  Denmark
Manufacturer / Brand:  Herofon / Herophon (brand of Hede Nielsen)
alternative name

Hede Nielsen's Fabrikker A/S
Year: 1957 ?? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: UCC85 UCH81 UF89 UABC80 UL84
Semiconductors (the count is only for transistors) Selen
Main principle Superheterodyne (common)
Wave bands Broadcast, (BC) Long Wave (LW), 2 x SW and FM or UHF.
Details Record Player (not changer)
Power type and voltage AC/DC-set / 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out
from Radiomuseum.org Model: Petite FM-FO-2-RG - Herofon / Herophon brand of
Material Wooden case
Shape Console, Lowboy (legs < 50 %).
Dimensions (WHD) 800 x 650 x 450 mm / 31.5 x 25.6 x 17.7 inch
Notes

Kleine Musiktruhe der Serie "Petite" mit Einfachplattenspieler "Collaro" (England).

Siehe auch das Tischgerät Petite FM-FO

Model page created by Albert Limmer. See "Data change" for further contributors.
