Jubilate W459U

Jubilate W459U; Horny Hornyphon; (ID = 1795951) Radio

Jubilate W459U; Horny Hornyphon; (ID = 1795952) Radio

Jubilate W459U; Horny Hornyphon; (ID = 20148) Radio

Jubilate W459U; Horny Hornyphon; (ID = 38179) Radio

Jubilate W459U; Horny Hornyphon; (ID = 1795953) Radio
Jubilate W459U; Horny Hornyphon; (ID = 902515) Radio Jubilate W459U; Horny Hornyphon; (ID = 902516) Radio
Jubilate W459U; Horny Hornyphon; (ID = 709442) Radio
Use red slider bar for more.
Jubilate W459U; Horny Hornyphon; (ID = 902515) Radio
Horny Hornyphon;: Jubilate W459U [Radio] ID = 902515 400x323
Select picture or schematic to display from thumbnails on the right and click for download.
For model Jubilate W459U, Horny (Hornyphon); Wien

Country:  Austria
Manufacturer / Brand:  Horny (Hornyphon); Wien
Brand

Hornyphon
Year: 1949/1950 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: UCH42 UAF42 UAF42 UL41 UM4 UY1N
Main principle Superheterodyne (common); ZF/IF 452 kHz
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast, Long Wave and 2 x Short Wave.
Details
Power type and voltage AC/DC-set / 110; 150; 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: Jubilate W459U - Horny Hornyphon; Wien
Material Wooden case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 420 x 300 x 210 mm / 16.5 x 11.8 x 8.3 inch
Notes

Parallelgerät zum Philips Adagio BA491U und Zerdik Z459U.

Net weight (2.2 lb = 1 kg) 6.8 kg / 14 lb 15.6 oz (14.978 lb)
Price in first year of sale 1'260.00 ATS
External source of data E. Erb 3-907007-36-0
Source of data Radiokatalog Band 2, Ernst Erb
Circuit diagram reference Unterlagen E.Erb
Literature/Schematics (1) -- Original-techn. papers.
Picture reference Das Modell ist im «Radiokatalog» (Erb) abgebildet.
