For model Souverän 54 W774A/I 3 Lautsprecher, Horny (Hornyphon); Wien

Country:  Austria
Manufacturer / Brand:  Horny (Hornyphon); Wien
Brand

Hornyphon
Year: 1954 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 8: EC92 EC92 ECH81 EF85 EM34 EABC80 EL84 EZ80
Main principle Super-Heterodyne (Super in general); ZF/IF 458/10700 kHz
Tuned circuits 7 AM circuit(s)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 110; 130; 150; 220; 240 Volt
Loudspeaker 3 Loudspeakers / Ø 22 cm = 8.7 inch
Power out
from Radiomuseum.org Model: Souverän 54 W774A/I [3 Lautsprecher] - Horny Hornyphon; Wien
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 530 x 420 x 266 mm / 20.9 x 16.5 x 10.5 inch
Notes

Parallelgerät zum Philips BA743A/1.

Lautsprecher mit 22 und 12cm. Sowie ein elektrostatischer mit 7cm.

Net weight (2.2 lb = 1 kg) 12.6 kg / 27 lb 12.1 oz (27.753 lb)
Price in first year of sale 2,950.00 ATS
Collectors' prices
External source of data E. Erb 3-907007-36-0
Source of data Radiokatalog Band 2, Ernst Erb
Circuit diagram reference Unterlagen E.Erb
Literature/Schematics (1) -- Original-techn. papers.
