• Country
• Germany

• Manufacturer / Brand
• Ihle, Max; Kulmbach und Grundmühle

• Year
• 1956/1957

• Category
• Sound/Video Recorder and/or Player

• Radiomuseum.org ID
• 20990

• Number of Tubes
• 6

• Valves / Tubes
• EF40 ECC83 EL41 EL84 EM71 AZ41

• Main principle
• Audio-Amplification

• Wave bands
• - without

• Details
• Tape Recorder

• Power type and voltage
• Alternating Current supply (AC) / 110; 220 Volt

• Power out
• 4 W (unknown quality)

• from Radiomuseum.org
• Model: Phono-Rex [EF40] - Ihle, Max; Kulmbach und Grundm

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 480 x 380 x 260 mm / 18.9 x 15 x 10.2 inch

• Notes
• Zweispur; 9,5/19 oder 19/38 cm/s.; Spulen-Ø 18 cm.

• Net weight (2.2 lb = 1 kg)
• 22 kg / 48 lb 7.3 oz (48.458 lb)

• Price in first year of sale
• 1,188.00 DM

• External source of data
• Erb

• Source of data
• HdB d.Rdf-& Ferns-GrH 1956/57 / Radiokatalog Band 2, Ernst Erb
