Ariane 414; Imperial Rundfunk (ID = 2363718) Radio
Imperial Rundfunk: Ariane 414 [Radio] ID = 2363718 1400x919
Select picture or schematic to display from thumbnails on the right and click for download.
For model Ariane 414, Imperial Rundfunk und Fernseh (Kuba-Imperial, auch General Electric); Osterode/Harz, Hemmingen:
Imperial Ariane 414 vorne

Country:  Germany
Manufacturer / Brand:  Imperial Rundfunk und Fernseh (Kuba-Imperial, auch General Electric); Osterode/Harz, Hemmingen
Year: 1960–1963 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: ECC85 ECH81 EF89 EABC80 EL95
Main principle Superheterodyne (common); ZF/IF 472/10700 kHz
Tuned circuits 6 AM circuit(s)     9 FM circuit(s)
Wave bands Broadcast, Long Wave and FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 110; 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out 3 W (unknown quality)
from Radiomuseum.org Model: Ariane 414 - Imperial Rundfunk und Fernseh
Material Bakelite case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 320 x 215 x 175 mm / 12.6 x 8.5 x 6.9 inch
Notes

Baugleich mit Kuba Kolibri.

Chassis von Körting.

Net weight (2.2 lb = 1 kg) 3.5 kg / 7 lb 11.3 oz (7.709 lb)
Price in first year of sale 180.00 DM
Source of data HdB d.Rdf-& Ferns-GrH 1960/61 / Radiokatalog Band 2, Ernst Erb
Literature/Schematics (1) -- Original-techn. papers.

Model page created by Arpad Roth † 27.3.17. See "Data change" for further contributors.
