VZ601

VZ601; Incar S.r.l.; (ID = 252704) Radio

VZ601; Incar S.r.l.; (ID = 2206411) Radio

VZ601; Incar S.r.l.; (ID = 2206412) Radio
Use red slider bar for more.
VZ601; Incar S.r.l.; (ID = 252704) Radio
Select picture or schematic to display from thumbnails on the right and click for download.

Country:  Italy
Manufacturer / Brand:  Incar S.r.l.; Vercelli
Year: 1951 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: ECH42 EBF32 6SL7 EL41 EL41 AZ2
Main principle Superheterodyne (common)
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast plus 2 Short Wave bands.
Details
Power type and voltage Alternating Current supply (AC) / 110; 125; 140; 160; 220 Volt
Loudspeaker Permanent or electro-dynamic (moving coil), system not known yet.
Power out 9 W (unknown quality)
from Radiomuseum.org Model: VZ601 - Incar S.r.l.; Vercelli
Material Wooden case
Shape Console: Chairside Radio.
Source of data Guida Pratica Antique Radio II (2000)
Literature/Schematics (1) Schemi di apparecchi radio ( Ravalico 1953 ) (pag. 104)

Model page created by Alessandro De Poi. See "Data change" for further contributors.



All listed radios etc. from Incar S.r.l.; Vercelli
Here you find 86 models, 49 with images and 43 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
