For model 401GW, Ingelen, Elektrotechnische Fabrik Ing. Ludwig Neumann GmbH; Wien:
Ingelen 401GW

Country:  Austria
Manufacturer / Brand:  Ingelen, Elektrotechnische Fabrik Ing. Ludwig Neumann GmbH; Wien
Brand

Elektrot.Fabrik Ludwig Neumann
Year: 1942–1944 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 4: UCH21 UCH21 UBL21 UY1N
Main principle Superheterodyne (common); ZF/IF 452 kHz
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast, Long Wave and Short Wave.
Details
Power type and voltage AC/DC-set / 117-220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: 401GW - Ingelen, Elektrotechnische
Material Bakelite case
Dimensions (WHD) 250 x 170 x 160 mm / 9.8 x 6.7 x 6.3 inch
Notes

Baugleich mit 1038L von Hornyphon / Pressburg.

Net weight (2.2 lb = 1 kg) 3 kg / 6 lb 9.7 oz (6.608 lb)
Collectors' prices
External source of data E. Erb 3-907007-36-0
Source of data Radiokatalog Band 2, Ernst Erb
Circuit diagram reference Lange-Nowisch
Mentioned in RADIOBOTE, Österr. (Heft 12/2007, S.10 ff, Gerätebeschreibung)
Literature/Schematics (1) -- Original-techn. papers.


All listed radios etc. from Ingelen, Elektrotechnische Fabrik Ing. Ludwig Neumann GmbH; Wien
Here you find 437 models, 383 with images and 317 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.






Forum contributions about this model
Ingelen,: 401GW
Threads: 1 | Posts: 1
Hits: 1529     Replies: 0
ingelen: 401GW;
Gerhard Heigl
10.Jan.04
  1 Näheres erfahren Sie unter http://www.radiomuseum.org/dsp_modell.cfm?model_id=8810
