UKW-Fidelio-3D W; Ingelen, (ID = 2022990) Radio
Ingelen,: UKW-Fidelio-3D W [Radio] ID = 2022990 1400x928
Select picture or schematic to display from thumbnails on the right and click for download.
For model UKW-Fidelio-3D W, Ingelen, Elektrotechnische Fabrik Ing. Ludwig Neumann GmbH; Wien

Country:  Austria
Manufacturer / Brand:  Ingelen, Elektrotechnische Fabrik Ing. Ludwig Neumann GmbH; Wien
Brand

Elektrot.Fabrik Ludwig Neumann
Year: 1955/1956 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 7: ECC85 ECH81 EF89 EABC80 EM80 EL84 EZ80
Main principle Superheterodyne (common); ZF/IF 459 kHz
Tuned circuits 6 AM circuit(s)     9 FM circuit(s)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 110-240 Volt
Loudspeaker 3 Loudspeakers
Power out
from Radiomuseum.org Model: UKW-Fidelio-3D W - Ingelen, Elektrotechnische
Material Wooden case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 530 x 352 x 234 mm / 20.9 x 13.9 x 9.2 inch
Notes 7 Tasten . Lautsprecher: Tiefton oval 18 x 23 cm, Mittelton 9 cm, Hochton 9 cm.
Net weight (2.2 lb = 1 kg) 11 kg / 24 lb 3.7 oz (24.229 lb)
Price in first year of sale 2'580.00 öS
External source of data E. Erb 3-907007-36-0
Source of data -- Original prospect or advert / Radiokatalog Band 2, Ernst Erb
Circuit diagram reference Unterlagen E.Erb


All listed radios etc. from Ingelen, Elektrotechnische Fabrik Ing. Ludwig Neumann GmbH; Wien
Here you find 439 models, 386 with images and 318 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
