For model LTV-1007, Invicta Radio, Barcelona:
Imagen del manual de usuario

Country:  Spain
Manufacturer / Brand:  Invicta Radio, Barcelona
alternative name

Establecimientos Lucarda || Radio Lucarda, S.L
Year: 1960 Category: Television Receiver (TV) or Monitor
Valves / Tubes 16: PCC88 PCF80 EF80 EF80 PCF80 PCL84 EF80 EF80 PCL82 PCF80 PCF80 PCF80 PL36 PY88 or PY81 DY87 PCL82 AW43-80
Main principle Superhet with RF-stage; ZF/IF 38900 kHz
Wave bands VHF incl. FM and/or UHF (see notes for details)
Details
Power type and voltage Alternating Current supply (AC) / 125 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out 3.5 W (undistorted)
from Radiomuseum.org Model: LTV-1007 - Invicta Radio, Barcelona
Shape Tablemodel, low profile (big size).
Notes

Invicta LTV-1007 TV B/N de 17" con selector rotativo de VHF de 10 canales

Mentioned in Anuncio La Vanguardia Española abril 1960
Literature/Schematics (1) - - Manufacturers Literature

Model page created by Miguel Bravo-Cos. See "Data change" for further contributors.
