• Country
• Spain

• Manufacturer / Brand
• Kastell; Madrid

• Year
• 1963

• Category
• Television Receiver (TV) or Monitor

• Radiomuseum.org ID
• 315365

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 18

• Valves / Tubes
• PCC189 PCF86 EF183 EF183 EF184 PCL84 PCF80 ECH84 PCF80 PCF80 PCL85 PL36 PY88 DY87 EF80 EF80 PCL86 AW47-91

• Number of Transistors

• Semiconductors
• OA70 OA70 OA85 OA210

• Main principle
• Superhet with RF-stage; ZF/IF 38900 kHz; 2 AF stage(s)

• Wave bands
• VHF incl. FM and/or UHF (see notes for details)

• Power type and voltage
• Alternating Current supply (AC) / 125; 220 Volt

• Loudspeaker
• 2 Loudspeakers

• Material
• Wooden case

• from Radiomuseum.org
• Model: 47-ML - Kastell; Madrid

• Shape
• Tablemodel, low profile (big size).

• Notes

• Kastell 47-ML

  TV B/N 19" con selector rotativo de VHF (canales 2-11).

  Dos altavoces elípticos de 4,5" x 6".

  Puede funcionar con redes de corriente continua polarizando el enchufe para que sea el negativo de la red el que vaya al chasis (chasis caliente).

  Véase mismo modelo en 23" 59-ML







• Price in first year of sale
• 16,928.00 Pts

• Mentioned in
• Hoja del lunes, Barcelona, mayo 1963; Esquemario TV REDE, Tomo I, 1964

• Literature/Schematics (1)
• -- Original-techn. papers.

• Author
• Model page created by Miguel Bravo-Cos. See "Data change" for further contributors.
