For model Piccolo 20130 Art.Nr. 821/10, Körting-Radio; Leipzig, später Grassau

Country:  Germany
Manufacturer / Brand:  Körting-Radio; Leipzig, später Grassau
alternative name

Dietz & Ritter GmbH, Dr.
Year: 1959/1960 ? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 7: ECC85 ECH81 EF89 EABC80 EM85 EL84 EZ80
Main principle Superheterodyne (common); ZF/IF 10700/472 kHz
Tuned circuits 6 AM circuit(s)     10 FM circuit(s)
Wave bands Broadcast, Long Wave and FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 110, 127, 155, 220, 240 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out 4 W (unknown quality)
from Radiomuseum.org Model: Piccolo 20130 Art.Nr. 821/10 - Körting-Radio; Leipzig, später
Material Bakelite case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 360 x 250 x 200 mm / 14.2 x 9.8 x 7.9 inch
Notes

Neckermann Art.Nr. 821/10
Ähnlich mit 805W Piccolino, mit EZ80.

Price in first year of sale 149.50 DM
Source of data Neckermann-Katalog

Model page created by Lutwin Berndt † 5.10.14. See "Data change" for further contributors.
