Billy 21020

Billy 21020; Körting-Radio; (ID = 293470) Radio

Billy 21020; Körting-Radio; (ID = 293495) Radio

Billy 21020; Körting-Radio; (ID = 293494) Radio
Billy 21020; Körting-Radio; (ID = 314656) Radio Billy 21020; Körting-Radio; (ID = 573664) Radio
Billy 21020; Körting-Radio; (ID = 573663) Radio Billy 21020; Körting-Radio; (ID = 314657) Radio
Billy 21020; Körting-Radio; (ID = 314658) Radio Billy 21020; Körting-Radio; (ID = 314659) Radio
Billy 21020; Körting-Radio; (ID = 573662) Radio Billy 21020; Körting-Radio; (ID = 573665) Radio
Billy 21020; Körting-Radio; (ID = 573666) Radio Billy 21020; Körting-Radio; (ID = 573667) Radio
Use red slider bar for more.
Billy 21020; Körting-Radio; (ID = 314656) Radio
Körting-Radio;: Billy 21020 [Radio] ID = 314656 533x400
Select picture or schematic to display from thumbnails on the right and click for download.
For model Billy 21020, Körting-Radio; Leipzig, später Grassau

Country:  Germany
Manufacturer / Brand:  Körting-Radio; Leipzig, später Grassau
alternative name

Dietz & Ritter GmbH, Dr.
Year: 1960 ?? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: ECC85 ECH81 EF89 EABC80 EL95
Main principle Superheterodyne (common); ZF/IF 472/10700 kHz; Export model
Tuned circuits 6 AM circuit(s)     9 FM circuit(s)
Wave bands Broadcast, Long Wave and FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 110/220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out
from Radiomuseum.org Model: Billy 21020 - Körting-Radio; Leipzig, später
Material Modern plastics (no Bakelite or Catalin)
Dimensions (WHD) 320 x 213 x 165 mm / 12.6 x 8.4 x 6.5 inch
Notes

UKW bis 100 MHz. 5 Tasten, eine davon als Tonblende «HELL».

Paralleltype zum Neckermann Rubin 21030.

Net weight (2.2 lb = 1 kg) 3.6 kg / 7 lb 14.9 oz (7.93 lb)
Literature/Schematics (1) -- Original-techn. papers.
