Puszta 56 Ch= Fidelio 56 m. Klangregister

Puszta 56 Ch= Fidelio 56; Kuba Kuba-Imperial, (ID = 675893) Radio Puszta 56 Ch= Fidelio 56; Kuba Kuba-Imperial, (ID = 675894) Radio
Puszta 56 Ch= Fidelio 56; Kuba Kuba-Imperial, (ID = 220546) Radio Puszta 56 Ch= Fidelio 56; Kuba Kuba-Imperial, (ID = 675895) Radio
Puszta 56 Ch= Fidelio 56; Kuba Kuba-Imperial, (ID = 1780060) Radio Puszta 56 Ch= Fidelio 56; Kuba Kuba-Imperial, (ID = 1780061) Radio
Puszta 56 Ch= Fidelio 56; Kuba Kuba-Imperial, (ID = 1780062) Radio Puszta 56 Ch= Fidelio 56; Kuba Kuba-Imperial, (ID = 2554780) Radio
Use red slider bar for more.
Puszta 56 Ch= Fidelio 56; Kuba Kuba-Imperial, (ID = 675893) Radio
Kuba Kuba-Imperial,: Puszta 56 Ch= Fidelio 56 [Radio] ID = 675893 396x400
Select picture or schematic to display from thumbnails on the right and click for download.
For model Puszta 56 Ch= Fidelio 56 m. Klangregister, Kuba (Kuba-Imperial), G. Kubetschek; Wolfenbüttel

Country:  Germany
Manufacturer / Brand:  Kuba (Kuba-Imperial), G. Kubetschek; Wolfenbüttel
alternative name

Imperial Kuba
Year: 1955/1956 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: ECC85 ECH81 EF85 EABC80 EM34 EL84
Main principle Superheterodyne (common); ZF/IF 460/10700 kHz
Tuned circuits 8 AM circuit(s)     11 FM circuit(s)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details Changer (Record changer)
Power type and voltage Alternating Current supply (AC) / 110; 125; 150; 220; 240 Volt
Loudspeaker 3 Loudspeakers
Power out 2.5 W (3.5 W max.)
from Radiomuseum.org Model: Puszta 56 Ch= Fidelio 56 [m. Klangregister] - Kuba Kuba-Imperial, G.
Material Wooden case
Shape Console with Push Buttons.
Dimensions (WHD) 820 x 840 x 450 mm / 32.3 x 33.1 x 17.7 inch
Notes Rundfunk-Chassis = Nordmende Fidelio 56;
Phono-Chassis = Philips AG1003.
Net weight (2.2 lb = 1 kg) 34 kg / 74 lb 14.2 oz (74.89 lb)
Price in first year of sale 648.00 DM
External source of data Erb
Source of data HdB d.Rdf-& Ferns-GrH 1955/56 / Radiokatalog Band 2, Ernst Erb


All listed radios etc. from Kuba (Kuba-Imperial), G. Kubetschek; Wolfenbüttel
Here you find 726 models, 673 with images and 270 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
