Admira 53 015 poliert

Admira 53 015; Loewe-Opta; (ID = 698437) Television

Admira 53 015; Loewe-Opta; (ID = 698438) Television

Admira 53 015; Loewe-Opta; (ID = 698441) Television

Admira 53 015; Loewe-Opta; (ID = 698443) Television

Admira 53 015; Loewe-Opta; (ID = 698444) Television

Admira 53 015; Loewe-Opta; (ID = 698445) Television

Admira 53 015; Loewe-Opta; (ID = 698446) Television
Use red slider bar for more.
Admira 53 015; Loewe-Opta; (ID = 698437) Television
Select picture or schematic to display from thumbnails on the right and click for download.

Country:  Germany
Manufacturer / Brand:  Loewe-(Opta); Deutschland
alternative name

Löwe Radio
Year: 1964/1965 Category: Television Receiver (TV) or Monitor
Valves / Tubes 17: PCC88 PCF80 PC88 PC86 EF183 EF80 EF80 PCL84 ECH84 PCL85 PL500 PY88 DY86 EF80 PCL86 PCF802 AW59-91
Main principle Super-Heterodyne (Super in general)
Wave bands Wave Bands given in the notes.
Details
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out
from Radiomuseum.org Model: Admira 53 015 [poliert] - Loewe-Opta; Deutschland
Material Wooden case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 650 x 480 x 290 mm / 25.6 x 18.9 x 11.4 inch
Notes VHF/UHF.
Net weight (2.2 lb = 1 kg) 34 kg / 74 lb 14.2 oz (74.89 lb)
Price in first year of sale 1'148.00 DM
External source of data Erb
Source of data Handbuch VDRG 1964/1965
