Atrium 606

Atrium 606; Loewe-Opta; (ID = 313288) Television Atrium 606; Loewe-Opta; (ID = 675604) Television
Use red slider bar for more.
Atrium 606; Loewe-Opta; (ID = 313288) Television
Loewe-Opta;: Atrium 606 [Television] ID = 313288 236x203
Select picture or schematic to display from thumbnails on the right and click for download.
For model Atrium 606, Loewe-(Opta); Deutschland

Country:  Germany
Manufacturer / Brand:  Loewe-(Opta); Deutschland
alternative name

Löwe Radio
Year: 1954/1955 Category: Television Receiver (TV) or Monitor
Valves / Tubes 17: PCC84 PCC85 EF80 EF80 EF80 EF80 PL83 EF80 PABC80 PL82 ECL80 ECL80 PY81 PL82 ECC82 PL81 EY51 MW43-64
Main principle Superheterodyne (common); ZF/IF 28750 kHz
Details Radio Control (+Remote Wire etc)
Power type and voltage AC/DC-set / 220 Volt
Loudspeaker 2 Loudspeakers / Ø 22 cm = 8.7 inch
Power out
from Radiomuseum.org Model: Atrium 606 - Loewe-Opta; Deutschland
Material Wooden case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 590 x 530 x 510 mm / 23.2 x 20.9 x 20.1 inch
Notes 10 VHF-Kanäle + 2 Reserve, Einbau UHF-Converter vorgesehen.
Net weight (2.2 lb = 1 kg) 35 kg / 77 lb 1.5 oz (77.093 lb)
Price in first year of sale 998.00 DM
External source of data Erb
Source of data Rundfunk- und Fernseh-Katalog 1954/55
