Iris 53 002 mattiert

Iris 53 002; Loewe-Opta; (ID = 289562) Television

Iris 53 002; Loewe-Opta; (ID = 289563) Television

Iris 53 002; Loewe-Opta; (ID = 289564) Television

Iris 53 002; Loewe-Opta; (ID = 739196) Television

Iris 53 002; Loewe-Opta; (ID = 739198) Television

Iris 53 002; Loewe-Opta; (ID = 739199) Television

Iris 53 002; Loewe-Opta; (ID = 739200) Television

Iris 53 002; Loewe-Opta; (ID = 739201) Television

Iris 53 002; Loewe-Opta; (ID = 739202) Television

Iris 53 002; Loewe-Opta; (ID = 739203) Television
Iris 53 002; Loewe-Opta; (ID = 739205) Television Iris 53 002; Loewe-Opta; (ID = 739206) Television
Use red slider bar for more.
Iris 53 002; Loewe-Opta; (ID = 739205) Television
Loewe-Opta;: Iris 53 002 [Television] ID = 739205 888x768
Select picture or schematic to display from thumbnails on the right and click for download.
For model Iris 53 002 mattiert, Loewe-(Opta); Deutschland:
Loewe Opta- Fernsehgeräte- Schaltungen 1964- 68

Country:  Germany
Manufacturer / Brand:  Loewe-(Opta); Deutschland
alternative name

Löwe Radio
Year: 1964/1965 Category: Television Receiver (TV) or Monitor
Valves / Tubes 15: PC900 PCF801 PC88 PC86 EF183 EF80 PCL84 PCH200 PCL85 PL500 PY88 DY86 PCL86 PCF802 AW59-91
Semiconductors (the count is only for transistors) 2:
Main principle Super-Heterodyne (Super in general)
Wave bands Wave Bands given in the notes.
Details
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out
from Radiomuseum.org Model: Iris 53 002 [mattiert] - Loewe-Opta; Deutschland
Material Wooden case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 615 x 505 x 295 mm / 24.2 x 19.9 x 11.6 inch
Notes VHF/UHF.
Net weight (2.2 lb = 1 kg) 33 kg / 72 lb 11 oz (72.687 lb)
Price in first year of sale 1'113.00 DM
External source of data Erb
Source of data Handbuch VDRG 1964/1965
