Komet 559W

Komet 559W; Loewe-Opta; (ID = 52080) Radio
Komet 559W; Loewe-Opta; (ID = 2371930) Radio Komet 559W; Loewe-Opta; (ID = 45955) Radio
Komet 559W; Loewe-Opta; (ID = 45956) Radio Komet 559W; Loewe-Opta; (ID = 45958) Radio
Komet 559W; Loewe-Opta; (ID = 45959) Radio Komet 559W; Loewe-Opta; (ID = 2371931) Radio
Komet 559W; Loewe-Opta; (ID = 2371932) Radio Komet 559W; Loewe-Opta; (ID = 2371933) Radio
Komet 559W; Loewe-Opta; (ID = 2371934) Radio Komet 559W; Loewe-Opta; (ID = 2371935) Radio
Use red slider bar for more.
Komet 559W; Loewe-Opta; (ID = 2371930) Radio
Loewe-Opta;: Komet 559W [Radio] ID = 2371930 1400x927
Select picture or schematic to display from thumbnails on the right and click for download.
For model Komet 559W, Loewe-(Opta); Deutschland

Country:  Germany
Manufacturer / Brand:  Loewe-(Opta); Deutschland
alternative name

Löwe Radio
Year: 1954/1955 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: ECC85 ECH81 EF85 EABC80 EM4 EL84
Main principle Super-Heterodyne (Super in general); ZF/IF 473/10700 kHz
Tuned circuits 9 AM circuit(s)     10 FM circuit(s)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 110-240 Volt
Loudspeaker 2 Loudspeakers
Power out
from Radiomuseum.org Model: Komet 559W - Loewe-Opta; Deutschland
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 590 x 380 x 280 mm / 23.2 x 15 x 11 inch
Notes

Bandfilter-Eingang; variable Bandbreite; KW-Lupe.

Net weight (2.2 lb = 1 kg) 11.8 kg / 25 lb 15.9 oz (25.991 lb)
Price in first year of sale 319.00 DM
Collectors' prices
Source of data Rundfunk- und Fernseh-Katalog 1954/55 / Radiokatalog Band 1, Ernst Erb
Picture reference Das Modell ist im «Radiokatalog» (Erb) abgebildet.


All listed radios etc. from Loewe-(Opta); Deutschland
Here you find 1566 models, 1294 with images and 1146 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
