Stadion 1678

Stadion 1678; Loewe-Opta; (ID = 324597) Television

Stadion 1678; Loewe-Opta; (ID = 324598) Television

Stadion 1678; Loewe-Opta; (ID = 324856) Television

Stadion 1678; Loewe-Opta; (ID = 324857) Television

Stadion 1678; Loewe-Opta; (ID = 744700) Television

Stadion 1678; Loewe-Opta; (ID = 744701) Television

Stadion 1678; Loewe-Opta; (ID = 744702) Television

Stadion 1678; Loewe-Opta; (ID = 744703) Television

Stadion 1678; Loewe-Opta; (ID = 744704) Television

Stadion 1678; Loewe-Opta; (ID = 744705) Television
Use red slider bar for more.
Stadion 1678; Loewe-Opta; (ID = 324597) Television
Select picture or schematic to display from thumbnails on the right and click for download.

Country:  Germany
Manufacturer / Brand:  Loewe-(Opta); Deutschland
alternative name

Löwe Radio
Year: 1960/1961 Category: Television Receiver (TV) or Monitor
Valves / Tubes 20: PCC88 PCF80 EF183 EF80 PCL84 EBF89 PABC80 PL84 ECH81 ECC82 PCL82 PL36 PY88 DY86 AW53-88
Main principle Superheterodyne (common); ZF/IF 38900 kHz
Wave bands Wave Bands given in the notes.
Details Radio Control (+Remote Wire etc)
Power type and voltage AC/DC-set / 220 Volt
Loudspeaker 2 Loudspeakers
Power out
from Radiomuseum.org Model: Stadion 1678 - Loewe-Opta; Deutschland
Material Wooden case
Shape Console with any shape - in general
Dimensions (WHD) 600 x 930 x 440 mm / 23.6 x 36.6 x 17.3 inch
Notes Technische Daten wie Arena 678.
Einige Röhren mehrfach vorhanden.
Net weight (2.2 lb = 1 kg) 53 kg / 116 lb 11.8 oz (116.74 lb)
Price in first year of sale 1'148.00 DM
Source of data HdB d.Rdf-& Ferns-GrH 1960/61
Literature/Schematics (1) -- Schematic

Model page created by Bernd P. Kieck. See "Data change" for further contributors.
