Thalia 1688; Loewe-Opta; (ID = 1563614) Television
Loewe-Opta;: Thalia 1688 [Television] ID = 1563614 933x986
Select picture or schematic to display from thumbnails on the right and click for download.
For model Thalia 1688, Loewe-(Opta); Deutschland:
Eigenes Gerät, Ansicht bei geöffneten Türen

Country:  Germany
Manufacturer / Brand:  Loewe-(Opta); Deutschland
alternative name

Löwe Radio
Year: 1960/1961 Category: Television Receiver (TV) or Monitor
Valves / Tubes 22: PCC88 PCF80 EF183 EF80 PCL84 EBF89 PABC80 PL84 PL36 PY88 DY86 PCL82 ECH81 ECC82 PC86 PC86 AW59-90
Main principle Superheterodyne (common)
Wave bands VHF incl. FM and/or UHF (see notes for details)
Details Radio Control (+Remote Wire etc)
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: Thalia 1688 - Loewe-Opta; Deutschland
Material Wooden case
Shape Console with any shape - in general
Dimensions (WHD) 602 x 935 x 475 mm / 23.7 x 36.8 x 18.7 inch
Notes

Röhren teilweise mehrfach vorhanden.

Ton-ZF 5,5 MHz, Anschluß für Kabelfernbedienung IV, Abstimmhilfe "Bildpeiler", automatische Scharfabstimmung, Zeilenautomatik, 2 Lautsprecher.

VHF-Tuner für Band I und III, UHF-Tuner Band IV und V 470 - 790MHz.



Mentioned in - - Manufacturers Literature (Loewe Opta - Fernsehgeräteschaltungen 1958-63 Ing. F. Möhring 1.Aufl.1966)

Model page created by Michael Salzgeber. See "Data change" for further contributors.
