VE301G; Loewe-Opta; (ID = 159822) Radio
Loewe-Opta;: VE301G [Radio] ID = 159822 525x700
Select picture or schematic to display from thumbnails on the right and click for download.
For model VE301G, Loewe-(Opta); Deutschland:
VE301G Loewe

Country:  Germany
Manufacturer / Brand:  Loewe-(Opta); Deutschland
alternative name

Löwe Radio
Year: 1933–1938 perfect model Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 2: REN1821 RENS1823d
Main principle TRF with regeneration; 1 AF stage(s)
Tuned circuits 1 AM circuit(s)
Wave bands Broadcast (MW) and Long Wave.
Details
Power type and voltage Direct Current supply (DC) / 110; 150; 220 Volt
Loudspeaker Magnetic loudspeaker (reed) of high quality (free mooving - only possible past 1931).
Power out
from Radiomuseum.org Model: VE301G - Loewe-Opta; Deutschland
Material Wooden case
Shape Tablemodel, high profile (upright - NOT Cathedral nor decorative).
Dimensions (WHD) 295 x 393 x 175 mm / 11.6 x 15.5 x 6.9 inch
Notes
Da nur Rückwand und meist das Typenschild den Hersteller zeigen, kann nicht immer nach diesem sortiert werden. Im übrigen sind die Produkte der verschiedenen Hersteller identisch.
Eine Auflistung aller deutschen Hersteller ist hier zu finden.

Model page created by Konrad Birkner † 12.08.2014. See "Data change" for further contributors.
