Verona 2804T (T/W)

Verona 2804T ; Loewe-Opta; (ID = 1002319) Radio
Verona 2804T ; Loewe-Opta; (ID = 210145) Radio Verona 2804T ; Loewe-Opta; (ID = 1973762) Radio
Verona 2804T ; Loewe-Opta; (ID = 1973763) Radio Verona 2804T ; Loewe-Opta; (ID = 1973764) Radio
Verona 2804T ; Loewe-Opta; (ID = 1973766) Radio Verona 2804T ; Loewe-Opta; (ID = 1973767) Radio
Verona 2804T ; Loewe-Opta; (ID = 1973770) Radio Verona 2804T ; Loewe-Opta; (ID = 1973772) Radio
Verona 2804T ; Loewe-Opta; (ID = 1973773) Radio Verona 2804T ; Loewe-Opta; (ID = 1973774) Radio
Use red slider bar for more.
Verona 2804T ; Loewe-Opta; (ID = 210145) Radio
Loewe-Opta;: Verona 2804T [Radio] ID = 210145 800x613
Select picture or schematic to display from thumbnails on the right and click for download.
For model Verona 2804T (T/W), Loewe-(Opta); Deutschland:
Bild aus 'Der Deutsche Rundfunk- Einzelhandel 1957'

Country:  Germany
Manufacturer / Brand:  Loewe-(Opta); Deutschland
alternative name

Löwe Radio
Year: 1957/1958 perfect model Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 7: ECC85 ECH81 EF89 EABC80 EM80 ECL82 ECL82
Main principle Superheterodyne (common)
Tuned circuits 6 AM circuit(s)     10 FM circuit(s)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details Changer (Record changer)
Power type and voltage Alternating Current supply (AC) / 110; 127; 150; 220 Volt
Loudspeaker 3 Loudspeakers
Power out
from Radiomuseum.org Model: Verona 2804T - Loewe-Opta; Deutschland
Material Wooden case
Shape Console with Push Buttons.
Dimensions (WHD) 1040 x 750 x 380 mm / 40.9 x 29.5 x 15 inch
Notes

Phono-Chassis = Perpetuum-Ebner Rex A/4..

Net weight (2.2 lb = 1 kg) 32 kg / 70 lb 7.8 oz (70.485 lb)
Price in first year of sale 748.00 DM
External source of data Erb
Source of data HdB d.Rdf-& Ferns-GrH 1957/58
