For model RD156, Marelli (Radiomarelli); Sesto San Giovanni (MI)
Country:  Italy
Manufacturer / Brand:  Marelli (Radiomarelli); Sesto San Giovanni (MI)
Year: 1955/1956 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 8: 12AT7 6BE6 6BA6 6AU6 6E5GT 6T8 50L6GT 5Y3GT
Main principle Superheterodyne (common); ZF/IF 455/10700 kHz
Tuned circuits 6 AM circuit(s)     11 FM circuit(s)
Wave bands Broadcast, Short Wave plus FM or UHF.
Power type and voltage Alternating Current supply (AC) / 110-220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 16 cm = 6.3 inch
Power out 3 W (unknown quality)
from Model: RD156 - Marelli Radiomarelli; Sesto
Material Wooden case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 520 x 320 x 240 mm / 20.5 x 12.6 x 9.4 inch
Notes Serie ANIE MF.
Net weight (2.2 lb = 1 kg) 9 kg / 19 lb 13.2 oz (19.824 lb)
Price in first year of sale 42'000.00 ITL
Source of data Guida Pratica Antique Radio (1) 1999
Mentioned in Catalogo ANIE (1955-56)
Literature/Schematics (1) Riparazioni - Scuola Radio Elettra (pag. M1 MF)
Literature/Schematics (2) -- Schematic (D.E. Ravalico, Il Radiolibro, 16° edizione, 1957, Hoepli)

Model page created by Alessandro De Poi. See "Data change" for further contributors.
