RD307-MF

RD307-MF; Marelli Radiomarelli (ID = 793169) Radio

RD307-MF; Marelli Radiomarelli (ID = 793170) Radio

RD307-MF; Marelli Radiomarelli (ID = 793171) Radio

RD307-MF; Marelli Radiomarelli (ID = 793172) Radio

RD307-MF; Marelli Radiomarelli (ID = 793173) Radio

RD307-MF; Marelli Radiomarelli (ID = 793175) Radio

RD307-MF; Marelli Radiomarelli (ID = 793176) Radio
RD307-MF; Marelli Radiomarelli (ID = 1039235) Radio RD307-MF; Marelli Radiomarelli (ID = 1039233) Radio
RD307-MF; Marelli Radiomarelli (ID = 1039234) Radio RD307-MF; Marelli Radiomarelli (ID = 1039236) Radio
RD307-MF; Marelli Radiomarelli (ID = 1039237) Radio
Use red slider bar for more.
RD307-MF; Marelli Radiomarelli (ID = 1039235) Radio
Marelli Radiomarelli: RD307-MF [Radio] ID = 1039235 750x562
Select picture or schematic to display from thumbnails on the right and click for download.
For model RD307-MF, Marelli (Radiomarelli); Sesto San Giovanni (MI)

Country:  Italy
Manufacturer / Brand:  Marelli (Radiomarelli); Sesto San Giovanni (MI)
Year: 1963–1966 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 9: AF114 AF115 AF116 AF116 AF116 OC71 OC71 OC74 OC74
Main principle Super-Heterodyne (Super in general)
Tuned circuits 7 AM circuit(s)     9 FM circuit(s)
Wave bands Broadcast (BC) and FM or UHF.
Details
Power type and voltage Dry Batteries / 6 x 1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out 1 W (unknown quality)
from Radiomuseum.org Model: RD307-MF - Marelli Radiomarelli; Sesto
Material Wooden case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 430 x 210 x 125 mm / 16.9 x 8.3 x 4.9 inch
Notes

Serie ANIE. Altoparlante 110x160 mm ad alta impedenza.
Illuminazione scala a pulsante.
Antenna a stilo per onde FM. Gamma FM 87-104 MHz.
Prezzo 1963: 39.900 lire; prezzo 1965: 34.500 lire.

Net weight (2.2 lb = 1 kg) 3.2 kg / 7 lb 0.8 oz (7.048 lb)
Price in first year of sale 39'900.00 ITL
Mentioned in Catalogo ANIE 1965-66
Literature/Schematics (1) Catalogo Radiomarelli 1965, mod. RML 126 12/64

Model page created by Eduard Abfalterer. See "Data change" for further contributors.
