M471

M471; Markofon-Radio, Ing. (ID = 11734) Radio
M471; Markofon-Radio, Ing. (ID = 922592) Radio M471; Markofon-Radio, Ing. (ID = 227555) Radio
M471; Markofon-Radio, Ing. (ID = 271203) Radio M471; Markofon-Radio, Ing. (ID = 271201) Radio
M471; Markofon-Radio, Ing. (ID = 227554) Radio M471; Markofon-Radio, Ing. (ID = 271202) Radio
M471; Markofon-Radio, Ing. (ID = 271204) Radio M471; Markofon-Radio, Ing. (ID = 922584) Radio
M471; Markofon-Radio, Ing. (ID = 922585) Radio M471; Markofon-Radio, Ing. (ID = 922587) Radio
Use red slider bar for more.
M471; Markofon-Radio, Ing. (ID = 922592) Radio
Markofon-Radio, Ing.: M471 [Radio] ID = 922592 933x709
Select picture or schematic to display from thumbnails on the right and click for download.
For model M471, Markofon-Radio, Ing. Markov a Spol; Brno

Country:  Czechoslovakia
Manufacturer / Brand:  Markofon-Radio, Ing. Markov a Spol; Brno
Year: 1939/1940 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: ECH11 EBF11 EL11 AZ1 EFM11
Main principle Superheterodyne (common); ZF/IF 128 kHz
Tuned circuits 7 AM circuit(s)
Wave bands Broadcast, Long Wave and Short Wave.
Details
Power type and voltage Alternating Current supply (AC) / 120; 150; 220; 240 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: M471 - Markofon-Radio, Ing. Markov a
Material Wooden case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 505 x 350 x 213 mm / 19.9 x 13.8 x 8.4 inch
Notes Sparschaltung zur Reduzierung der Leistungsaufnahme durch Umschaltung der Sekundärwicklungen.
External source of data Erb
Source of data Ceskoslovenske prijimace 1933-1945, Baudys 1947


All listed radios etc. from Markofon-Radio, Ing. Markov a Spol; Brno
Here you find 25 models, 17 with images and 11 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
