MD5525A
Mediator; La Chaux-de-Fonds
- Country
- Switzerland
- Manufacturer / Brand
- Mediator; La Chaux-de-Fonds
- Year
- 1957
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 284222
By courtesy of Benjamin Arnold, Switzerland.
By courtesy of Benjamin Arnold, Switzerland.
By courtesy of Benjamin Arnold, Switzerland.
By courtesy of Benjamin Arnold, Switzerland.
By courtesy of Benjamin Arnold, Switzerland.
By courtesy of Benjamin Arnold, Switzerland.
By courtesy of Benjamin Arnold, Switzerland.
By courtesy of Benjamin Arnold, Switzerland.
By courtesy of Benjamin Arnold, Switzerland.
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 7
- Main principle
- Superheterodyne (common); ZF/IF 452/10700 kHz
- Wave bands
- Broadcast, Long Wave, Short Wave plus FM or UHF.
- Power type and voltage
- Alternating Current supply (AC) / 220 Volt
- Loudspeaker
- 3 Loudspeakers
- Material
- Wooden case
- from Radiomuseum.org
- Model: MD5525A - Mediator; La Chaux-de-Fonds
- Shape
- Tablemodel with Push Buttons.
- Dimensions (WHD)
- 520 x 310 x 220 mm / 20.5 x 12.2 x 8.7 inch
- Notes
-
Siehe auch Modell Philips Merkur BD473A.
- Source of data
- - - Manufacturers Literature
- Author
- Model page created by Ernst Erb. See "Data change" for further contributors.
