Mende - Radio H.: M153W [Radio] ID = 2386529 1400x1050
Select picture or schematic to display from thumbnails on the right and click for download.
For model M153W (153W), Mende - Radio H. Mende & Co. GmbH, Dresden

Country:  Germany
Manufacturer / Brand:  Mende - Radio H. Mende & Co. GmbH, Dresden
Brand

System Günther
Year: 1939/1940 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 4: AF3 AF7 AL4 AZ1
Main principle TRF with regeneration; 1 Special; 1 AF stage(s)
Tuned circuits 2 AM circuit(s)
Wave bands Broadcast (MW) and Long Wave.
Details
Power type and voltage Alternating Current supply (AC) / 110; 125; 220; 240 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 16 cm = 6.3 inch
Power out
from Radiomuseum.org Model: M153W - Mende - Radio H. Mende & Co.
Material Bakelite case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 540 x 285 x 265 mm / 21.3 x 11.2 x 10.4 inch
Notes

Mendelithgehäuse.

Das Typschild des Empfängers zeigt M153W, dagegen führen die Service-Unterlagen die Typbezeichnung 153W. Es handelt sich dabei um dasselbe Modell.

Net weight (2.2 lb = 1 kg) 12 kg / 26 lb 6.9 oz (26.432 lb)
Price in first year of sale 153.00 RM
Source of data Handbuch WDRG 1939 / Radiokatalog Band 1, Ernst Erb
Circuit diagram reference Röhren in FS-Bestückungstabellen
Picture reference Das Modell ist im «Radiokatalog» (Erb) abgebildet.
