162W; Mende - Radio H. (ID = 21033) Radio

162W; Mende - Radio H. (ID = 21034) Radio

162W; Mende - Radio H. (ID = 1112495) Radio

162W; Mende - Radio H. (ID = 2114948) Radio
162W; Mende - Radio H. (ID = 2274210) Radio 162W; Mende - Radio H. (ID = 2274209) Radio
162W; Mende - Radio H. (ID = 2274212) Radio 162W; Mende - Radio H. (ID = 708157) Radio
162W; Mende - Radio H. (ID = 2111043) Radio 162W; Mende - Radio H. (ID = 2274215) Radio
162W; Mende - Radio H. (ID = 2274216) Radio 162W; Mende - Radio H. (ID = 2274217) Radio
162W; Mende - Radio H. (ID = 2274218) Radio 162W; Mende - Radio H. (ID = 2274219) Radio
Use red slider bar for more.
162W; Mende - Radio H. (ID = 2274210) Radio
Mende - Radio H.: 162W [Radio] ID = 2274210 1400x1772
Select picture or schematic to display from thumbnails on the right and click for download.
For model 162W, Mende - Radio H. Mende & Co. GmbH, Dresden

Country:  Germany
Manufacturer / Brand:  Mende - Radio H. Mende & Co. GmbH, Dresden
Brand

System Günther
Year: 1931/1932 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 4: REN904 REN904 RE134 or RES164 RGN354
Main principle TRF with regeneration; 2 AF stage(s)
Tuned circuits 1 AM circuit(s)
Wave bands Broadcast (MW) and Long Wave.
Details
Power type and voltage Alternating Current supply (AC) / 110; 125; 150; 220 Volt
Loudspeaker Magnetic loudspeaker (reed) of high quality (4 magnet poles).
Power out
from Radiomuseum.org Model: 162W - Mende - Radio H. Mende & Co.
Material Wooden case
Shape Tablemodel, high profile (upright - NOT Cathedral nor decorative).
Dimensions (WHD) 380 x 488 x 225 mm / 15 x 19.2 x 8.9 inch
Notes

In den bekannten Katalogen wird der 162 W als 98 W mit eingebautem Lautsprecher bezeichnet.

Es handelt sich jedoch eindeutig um das Chassis eines 108 W, unzweifelhaft erkennbar am eingebauten Sperrkreis an der rechten Gehäuseseite.

Net weight (2.2 lb = 1 kg) 7.2 kg / 15 lb 13.7 oz (15.859 lb)
Price in first year of sale 162.00 RM +
Source of data Katalog Radio-Zentrale Prohaska 1931/32 / Radiokatalog Band 1, Ernst Erb
Circuit diagram reference Lange + FS-Bestückungstabellen
Mentioned in Radio-Schnorr-Katalog Nr.53 1931/32
Picture reference Das Modell ist im «Radiokatalog» (Erb) abgebildet.


All listed radios etc. from Mende - Radio H. Mende & Co. GmbH, Dresden
Here you find 309 models, 279 with images and 202 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
