• Country
• Germany

• Manufacturer / Brand
• Metz Transformatoren- und Apparatefabrik (ex TAM), Fürth

• Year
• 1955/1956

• Category
• Television- and Radio Receiver, perh. also + Rec. etc. (TV Radio)

• Radiomuseum.org ID
• 20247

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 18

• Valves / Tubes
• PCC85 ECH81 PCC84 PCC85 EF80 EF80 EF80 PL83 EF80 PCL82 PCF80 ECL80 PCL82 ECC82 PL81 PY81 EY86 MW43-64

• Tuned circuits
• 10 FM circuit(s)

• Wave bands
• Wave Bands given in the notes.

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical

• Material
• Wooden case

• from Radiomuseum.org
• Model: 910 - Metz Transformatoren- und

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 550 x 500 x 500 mm / 21.7 x 19.7 x 19.7 inch

• Notes
• Mit UKW Empfangsteil.

• Price in first year of sale
• 828.00 DM

• External source of data
• Erb

• Source of data
• HdB d.Rdf-& Ferns-GrH 1955/56

• Literature/Schematics (1)
• -- Original-techn. papers.

Fernsehgerät Metz 910

1104 KB
