For model Wireless Set No.18, MILITARY U.K. (different makers for same model)

Country:  Great Britain (UK)
Manufacturer / Brand:  MILITARY U.K. (different makers for same model)
Year: 1940 Category: Military Equipment
Valves / Tubes 6: AR8 ATP4 ARP12 ARP12 ARP12 AR8
Main principle Transceiver; ZF/IF 465 kHz
Wave bands Short Wave (SW only)
Details
Power type and voltage Dry Batteries / 150 & 3 Volt
Loudspeaker - For headphones or amp.
Power out
from Radiomuseum.org Model: Wireless Set No.18 - MILITARY U.K. different makers
Material Leather / canvas / plastic - over other material
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 10.5 x 17.5 x 11 inch / 267 x 445 x 279 mm
Notes Wireless set No. 18: Short range man-pack transceiver covering 6 - 9 MHz, AM (A3) (CW, only in sets Mk.II / Mk.III), pout 0,25 Watt telephony;
powered by LT 3 V and HT 150 V dry batteries; used by British Army for short range communications between company and battalion HQ or carried as man-pack on march;
The original Wireless Set No.8 was produced around 1940, production was changed from the heavy steel cabinet to a lighweight version becoming the Wireless Set 18.
Very similar sets have been produced in USA (Wireless Set No.48), in Canada (Wireless Set No.58) and Australia (Wireless Set No.108)
In 1943, a low frequency variant has been developed, it became Wireless Set No.68.
Mentioned in Wireless for the Warrior Vol. 1, L. Meulstee

Model page created by Martin Bösch. See "Data change" for further contributors.
