Minerphon W

Minerphon W; Minerva-Radio (ID = 71646) Radio
Minerphon W; Minerva-Radio (ID = 1130012) Radio Minerphon W; Minerva-Radio (ID = 995624) Radio
Minerphon W; Minerva-Radio (ID = 85938) Radio Minerphon W; Minerva-Radio (ID = 1164446) Radio
Minerphon W; Minerva-Radio (ID = 1164835) Radio Minerphon W; Minerva-Radio (ID = 1253607) Radio
Minerphon W; Minerva-Radio (ID = 74254) Radio Minerphon W; Minerva-Radio (ID = 413065) Radio
Minerphon W; Minerva-Radio (ID = 413066) Radio Minerphon W; Minerva-Radio (ID = 413067) Radio
Use red slider bar for more.
Minerphon W; Minerva-Radio (ID = 1130012) Radio
Minerva-Radio: Minerphon W [Radio] ID = 1130012 782x933
Select picture or schematic to display from thumbnails on the right and click for download.
For model Minerphon W, Minerva-Radio (Radiola-Radioapparate und Bestandteile W. Wohleber & Co) ; Wien:
Bild von Gerhard Köhldorfer.

Country:  Austria
Manufacturer / Brand:  Minerva-Radio (Radiola-Radioapparate und Bestandteile W. Wohleber & Co) ; Wien
Year: 1952/1953 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: ECH42 EAF42 EBC41 EL41 EM34 AZ41
Main principle Superheterodyne (common)
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast, Long Wave and Short Wave.
Details Record Player (not changer)
Power type and voltage Alternating Current supply (AC) / 110; 130; 150; 220; 240 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: Minerphon W - Minerva-Radio Radiola-
Material Wooden case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 485 x 400 x 350 mm / 19.1 x 15.7 x 13.8 inch
Notes Es wurden mindestens drei verschiedene Laufwerke verbaut. Z.B.: Philips 2978 oder Fa. Elac.
Net weight (2.2 lb = 1 kg) 16 kg / 35 lb 3.9 oz (35.242 lb)
Price in first year of sale 2'680.00 ATS
External source of data E. Erb 3-907007-36-0
Source of data Radiokatalog Band 2, Ernst Erb
Literature/Schematics (1) -- Original-techn. papers.


All listed radios etc. from Minerva-Radio (Radiola-Radioapparate und Bestandteile W. Wohleber & Co) ; Wien
Here you find 627 models, 557 with images and 446 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
