Minola 2 593N

Minola 2 593N; Minerva-Radio (ID = 55373) Radio

Minola 2 593N; Minerva-Radio (ID = 141366) Radio

Minola 2 593N; Minerva-Radio (ID = 141485) Radio

Minola 2 593N; Minerva-Radio (ID = 141486) Radio
Minola 2 593N; Minerva-Radio (ID = 2535440) Radio Minola 2 593N; Minerva-Radio (ID = 2471475) Radio
Minola 2 593N; Minerva-Radio (ID = 109398) Radio Minola 2 593N; Minerva-Radio (ID = 109399) Radio
Minola 2 593N; Minerva-Radio (ID = 109400) Radio Minola 2 593N; Minerva-Radio (ID = 60263) Radio
Minola 2 593N; Minerva-Radio (ID = 58012) Radio Minola 2 593N; Minerva-Radio (ID = 65692) Radio
Minola 2 593N; Minerva-Radio (ID = 209555) Radio Minola 2 593N; Minerva-Radio (ID = 209558) Radio
Use red slider bar for more.
Minola 2 593N; Minerva-Radio (ID = 2535440) Radio
Minerva-Radio: Minola 2 593N [Radio] ID = 2535440 1280x785
Select picture or schematic to display from thumbnails on the right and click for download.
For model Minola 2 593N, Minerva-Radio (Radiola-Radioapparate und Bestandteile W. Wohleber & Co) ; Wien

Country:  Austria
Manufacturer / Brand:  Minerva-Radio (Radiola-Radioapparate und Bestandteile W. Wohleber & Co) ; Wien
Year: 1963/1964 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 7: ECC85 ECH81 EF89 EABC80 EM84 EL84 EZ80
Main principle Superheterodyne (common); ZF/IF 461/10700 kHz
Tuned circuits 6 AM circuit(s)     9 FM circuit(s)
Wave bands Broadcast, Long Wave and FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 220/240 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical / Ø 14 cm = 5.5 inch
Power out
from Radiomuseum.org Model: Minola 2 593N - Minerva-Radio Radiola-
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 440 x 270 x 175 mm / 17.3 x 10.6 x 6.9 inch
Net weight (2.2 lb = 1 kg) 6.7 kg / 14 lb 12.1 oz (14.758 lb)
Price in first year of sale 1'695.00 ATS
External source of data E. Erb 3-907007-36-0
Source of data -- Original-techn. papers. / Radiokatalog Band 2, Ernst Erb
Literature/Schematics (1) -- Original-techn. papers.


All listed radios etc. from Minerva-Radio (Radiola-Radioapparate und Bestandteile W. Wohleber & Co) ; Wien
Here you find 627 models, 557 with images and 446 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
