Resident 646 23 Zoll

Resident 646; Minerva-Radio (ID = 139319) Television

Resident 646; Minerva-Radio (ID = 139320) Television

Resident 646; Minerva-Radio (ID = 139321) Television
Resident 646; Minerva-Radio (ID = 1791248) Television Resident 646; Minerva-Radio (ID = 139318) Television
Resident 646; Minerva-Radio (ID = 1791249) Television Resident 646; Minerva-Radio (ID = 1791250) Television
Use red slider bar for more.
Resident 646; Minerva-Radio (ID = 1791248) Television
Minerva-Radio: Resident 646 [Television] ID = 1791248 640x480
Select picture or schematic to display from thumbnails on the right and click for download.
For model Resident 646 23 Zoll, Minerva-Radio (Radiola-Radioapparate und Bestandteile W. Wohleber & Co) ; Wien

Country:  Austria
Manufacturer / Brand:  Minerva-Radio (Radiola-Radioapparate und Bestandteile W. Wohleber & Co) ; Wien
Year: 1963 Category: Television Receiver (TV) or Monitor
Valves / Tubes 18: PC88 PC86 PCC189 PCF86 EF183 EF80 EF184 PCL84 ECH84 PCF80 PCL85 PCL86 PL500 PY88 DY87 23SP4
Semiconductors (the count is only for transistors) 2:
Main principle Superheterodyne (common)
Wave bands Wave Bands given in the notes.
Details
Power type and voltage AC/DC-set / 220; 240 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: Resident 646 [23 Zoll] - Minerva-Radio Radiola-
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 700 x 540 x 385 mm / 27.6 x 21.3 x 15.2 inch
Notes Röhren teilweise mehrfach. Fernsehband I und III (Kanäle 2-12 und 2A), Band IV/V (Kanäle 21-60). 23-Zoll-Bildröhre. Ausführung als nur UHF-vorbereitet 5980.- öS.
Net weight (2.2 lb = 1 kg) 30 kg / 66 lb 1.3 oz (66.079 lb)
Price in first year of sale 6'580.00 öS
Source of data -- Original-techn. papers. / Radiokatalog Band 2, Ernst Erb
Mentioned in -- Original prospect or advert
Literature/Schematics (1) -- Original-techn. papers.

Model page created by Hannes Wurnitsch. See "Data change" for further contributors.
