Othello 55/3DR Ch= 4060

Othello 55/3DR Ch= 4060; Nordmende, (ID = 659406) Radio

Othello 55/3DR Ch= 4060; Nordmende, (ID = 659407) Radio

Othello 55/3DR Ch= 4060; Nordmende, (ID = 659408) Radio

Othello 55/3DR Ch= 4060; Nordmende, (ID = 659411) Radio

Othello 55/3DR Ch= 4060; Nordmende, (ID = 659409) Radio

Othello 55/3DR Ch= 4060; Nordmende, (ID = 51958) Radio
Othello 55/3DR Ch= 4060; Nordmende, (ID = 61766) Radio Othello 55/3DR Ch= 4060; Nordmende, (ID = 61769) Radio
Othello 55/3DR Ch= 4060; Nordmende, (ID = 61768) Radio Othello 55/3DR Ch= 4060; Nordmende, (ID = 1577855) Radio
Othello 55/3DR Ch= 4060; Nordmende, (ID = 61767) Radio Othello 55/3DR Ch= 4060; Nordmende, (ID = 61771) Radio
Othello 55/3DR Ch= 4060; Nordmende, (ID = 61770) Radio Othello 55/3DR Ch= 4060; Nordmende, (ID = 72320) Radio
Othello 55/3DR Ch= 4060; Nordmende, (ID = 88737) Radio Othello 55/3DR Ch= 4060; Nordmende, (ID = 88738) Radio
Use red slider bar for more.
Othello 55/3DR Ch= 4060; Nordmende, (ID = 61766) Radio
Nordmende,: Othello 55/3DR Ch= 4060 [Radio] ID = 61766 691x434
Select picture or schematic to display from thumbnails on the right and click for download.
For model Othello 55/3DR Ch= 4060, Nordmende, Norddeutsche Mende-Rundfunk GmbH (Sterling), Bremen-Hemelingen

Country:  Germany
Manufacturer / Brand:  Nordmende, Norddeutsche Mende-Rundfunk GmbH (Sterling), Bremen-Hemelingen
Year: 1954/1955 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 7: EC92 EC92 ECH81 EF85 EM34 EABC80 EL84
Main principle Super-Heterodyne (Super in general); ZF/IF 468/10700 kHz
Tuned circuits 6 AM circuit(s)     11 FM circuit(s)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 110, 125, 150, 220, 240 Volt
Loudspeaker 4 Loudspeakers
Power out 5.5 W (unknown quality)
from Radiomuseum.org Model: Othello 55/3DR Ch= 4060 - Nordmende, Norddeutsche Mende-
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 660 x 405 x 275 mm / 26 x 15.9 x 10.8 inch
Notes Drehbare Ferritantenne, MW-Ortssendertaste. Bandbreite schaltbar.
Net weight (2.2 lb = 1 kg) 12.5 kg / 27 lb 8.5 oz (27.533 lb)
Price in first year of sale 430.00 DM
Collectors' prices
External source of data Erb
Source of data Rundfunk- und Fernseh-Katalog 1954/55
Literature/Schematics (1) -- Original-techn. papers.
