Universal-Wobbler UW 342/2-U
Nordmende, Norddeutsche Mende-Rundfunk GmbH (Sterling), Bremen-Hemelingen
- Country
- Germany
- Manufacturer / Brand
- Nordmende, Norddeutsche Mende-Rundfunk GmbH (Sterling), Bremen-Hemelingen
- Year
- 1965 ?
- Category
- Service- or Lab Equipment
- Radiomuseum.org ID
- 84931
Q: Nordmende, Service-Unterlagen
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 10
- Number of Transistors
- 3
- Wave bands
- Wave Bands given in the notes.
- Power type and voltage
- Alternating Current supply (AC) / 110; 220 Volt
- Loudspeaker
- - - No sound reproduction output.
- Material
- Metal case
- from Radiomuseum.org
- Model: Universal-Wobbler UW 342/2-U - Nordmende, Norddeutsche Mende-
- Shape
- Tablemodel, with any shape - general.
- Dimensions (WHD)
- 320 x 330 x 265 mm / 12.6 x 13 x 10.4 inch
- Notes
-
Meßsender mit Wobbler und Markengeber. Frequenzbereiche: 4 / 6,5 / 9,5 / 16 / 28 / 42 / 110 / 130 / 174 / 235 / 460-850 MHz.
- Net weight (2.2 lb = 1 kg)
- 16.2 kg / 35 lb 10.9 oz (35.683 lb)
- Price in first year of sale
- 1,793.00 DM
- Author
- Model page created by Marc Goeritz. See "Data change" for further contributors.
