For model Aristona H57A, NSF (Nederlandsche Seintoestellen Fabriek); Leuven:
Courtesy by Jeroen Landman (NL).

Country:  Belgium
Manufacturer / Brand:  NSF (Nederlandsche Seintoestellen Fabriek); Leuven
Year: 1938 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: EK2 EF5 EBC3 EBL1 EM1 AZ1
Main principle Superheterodyne (common); ZF/IF 128 kHz
Wave bands Broadcast (MW) and Long Wave.
Details
Power type and voltage Alternating Current supply (AC) / 6 taps: 110; 125; 145; 200; 220; 240 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 20 cm = 7.9 inch
Power out 3.5 W (unknown quality)
from Radiomuseum.org Model: Aristona H57A - NSF Nederlandsche
Material Wooden case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 490 x 364 x 245 mm / 19.3 x 14.3 x 9.6 inch
Notes We found the model Mullard X57A to have the same cabinet and tube line up as this Aristona H57A - and it is probably equal in the inside. The same cabinet has also the Swiss Mediator M57A (see small differences how the back wall is mounted) and inside is probably also the same.
Net weight (2.2 lb = 1 kg) 13.7 kg / 30 lb 2.8 oz (30.176 lb)
Price in first year of sale 2'375.00 Bfr
Mentioned in Radio Handboek 1940
