441

441; Orion; Budapest (ID = 164881) Radio

441; Orion; Budapest (ID = 1896771) Radio
441; Orion; Budapest (ID = 2055990) Radio 441; Orion; Budapest (ID = 383645) Radio
441; Orion; Budapest (ID = 135767) Radio 441; Orion; Budapest (ID = 2055987) Radio
441; Orion; Budapest (ID = 2055988) Radio 441; Orion; Budapest (ID = 2055989) Radio
441; Orion; Budapest (ID = 2206786) Radio 441; Orion; Budapest (ID = 2283198) Radio
441; Orion; Budapest (ID = 2283199) Radio 441; Orion; Budapest (ID = 2283200) Radio
Use red slider bar for more.
441; Orion; Budapest (ID = 2055990) Radio
Orion; Budapest: 441 [Radio] ID = 2055990 1400x967
Select picture or schematic to display from thumbnails on the right and click for download.
For model 441, Orion; Budapest:
Thanks for Mr.Ferenc Tóth, Hungary, Pomáz and Első Zalai Rádiómúzeum Alapítvány, First Zala County Radio Museum Foundation.

Country:  Hungary
Manufacturer / Brand:  Orion; Budapest
Year: 1950 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: ECH21 ECH21 EBL21 EM4 AZ1
Main principle Superheterodyne (common); ZF/IF 473 kHz
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast, Long Wave and more than two Short Wave bands.
Details
Power type and voltage Alternating Current supply (AC) / 107; 125; 132; 150; 185; 215; 240 Volt
Loudspeaker Permanent or electro-dynamic (moving coil), system not known yet.
Power out
from Radiomuseum.org Model: 441 - Orion; Budapest
Material Wooden case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 550 x 400 x 270 mm / 21.7 x 15.7 x 10.6 inch
Notes Schlüsselröhren; Pultform
Net weight (2.2 lb = 1 kg) 14 kg / 30 lb 13.4 oz (30.837 lb)
External source of data E. Erb 3-907007-36-0
Mentioned in Rádiókészülékek Kapcsolásai 1936-56
