520AG 020

520AG; Orion; Budapest (ID = 521077) Radio 520AG; Orion; Budapest (ID = 521078) Radio
520AG; Orion; Budapest (ID = 1771140) Radio 520AG; Orion; Budapest (ID = 1771141) Radio
520AG; Orion; Budapest (ID = 2238996) Radio 520AG; Orion; Budapest (ID = 2238997) Radio
520AG; Orion; Budapest (ID = 2239006) Radio 520AG; Orion; Budapest (ID = 2239007) Radio
Use red slider bar for more.
520AG; Orion; Budapest (ID = 521077) Radio
Orion; Budapest: 520AG [Radio] ID = 521077 550x432
Select picture or schematic to display from thumbnails on the right and click for download.
For model 520AG 020, Orion; Budapest:
Quelle: Radio Muzeum, STS kollection, .zalaszam.hu/radio .

Country:  Hungary
Manufacturer / Brand:  Orion; Budapest
Year: 1954/1955 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: ECH42 EAF42 EAF42 EL41 EM4 AZ41
Main principle Superheterodyne (common); ZF/IF 473,6 kHz
Wave bands Broadcast plus more than 2 Short Wave bands.
Details Record Player (not changer)
Power type and voltage Alternating Current supply (AC) / 110; 127; 150; 220; 240 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 20 cm = 7.9 inch
Power out 1.5 W (unknown quality)
from Radiomuseum.org Model: 520AG [020] - Orion; Budapest
Material Wooden case
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 510 x 410 x 360 mm / 20.1 x 16.1 x 14.2 inch
Notes SW1: Marine band, 2-5,75 MHz.
Speed: 78, 45 & 33 rpm.
Net weight (2.2 lb = 1 kg) 18 kg / 39 lb 10.4 oz (39.648 lb)
Price in first year of sale 2'980.00 HUF
Source of data Radio es Televizio Vevö keszülekek, 1956-57
Literature/Schematics (4) Villamossági tömegcikkek árjegyzéke Bp. 1955

Model page created by Sandor Selyem-Tóth. See "Data change" for further contributors.
