• Country
• Netherlands

• Manufacturer / Brand
• Philips; Eindhoven (tubes international!); Miniwatt

• Year
• 1961–1964 ??

• Category
• Television Receiver (TV) or Monitor

• Radiomuseum.org ID
• 189906

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 26

• Valves / Tubes
• EF184 EF184 PCL82 PL84 PCC88 PCF80 EF183 EF183 EF184 PCF80 PCL84 ECC82 PCF80 PCF80 PL36 PY81 DY87 ECC82 ECH83 PCF80 PF86 PCL85 PC88 PC86 PCF80 AW59-90

• Main principle
• Superheterodyne (common); 2 AF stage(s)

• Wave bands
• VHF incl. FM and/or UHF (see notes for details)

• Details
• Radio Control (+Remote Wire etc)

• Power type and voltage
• Alternating Current supply (AC) / 110; 127; 220 Volt

• Loudspeaker
• 2 Loudspeakers

• Material
• Wooden case

• from Radiomuseum.org
• Model: 23TX302A /01B - Philips; Eindhoven tubes

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 695 x 495 x 405 mm / 27.4 x 19.5 x 15.9 inch

• Notes
• • Transformerless audio output stage.
  • 5 standard receiver:
    • European 625 lines; FM sound; negative video sync.
    • Belgian 625 lines; AM sound; positive video sync.
    • Belgian 819 lines; AM sound; positive video sync.
    • French 819 lines; AM sound; positive video sync.
    • French UHF 625 lines; AM sound; positive video sync.
  • Type of loudspeakers: 1 x AD3800AM; 1 x AD2300CZ.
  • VHF channels: E2-E11; F6; F8a.
  • UHF 470-790 MHz.
  • Remote control unit AT6320-03.

• Source of data
• -- Original-techn. papers.
