Loisirs 461A; Philips France; (ID = 602004) Radio
Philips France;: Loisirs 461A [Radio] ID = 602004 320x240
Select picture or schematic to display from thumbnails on the right and click for download.
For model Loisirs 461A, Philips France; Paris

Country:  France
Manufacturer / Brand:  Philips France; Paris
Year: 1937/1938 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: AK2 AF3 ABC1 AL4 AZ1
Main principle Super-Heterodyne (Super in general); ZF/IF 128 kHz
Tuned circuits 7 AM circuit(s)
Wave bands Broadcast, Long Wave and Short Wave.
Details
Power type and voltage Alternating Current supply (AC) / 110-240 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 21 cm = 8.3 inch
Power out
from Radiomuseum.org Model: Loisirs 461A - Philips France; Paris
Material Bakelite case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 505 x 325 x 180 mm / 19.9 x 12.8 x 7.1 inch
Notes

3 gammes d'ondes : OC de 16.7 à 51 m, PO de 198 à 585 m, et GO de 720 à 2000 m. Présélecteur à 2 circuits. Antifading efficace. Contrôle de tonalité. Montage tri-bloc. Prises pour pick-up et HP supplémentaire. Lampe cadran 8042D, 4 V / 0.5 A.

Coffret en philite brune / matière plastique.

Voir aussi Loisirs 461A -29 avec FI de 118 Kc. Équivalent au Radiola RA43A.

Net weight (2.2 lb = 1 kg) 9.850 kg / 21 lb 11.1 oz (21.696 lb)
Collectors' prices
Mentioned in -- Original-techn. papers.
Literature/Schematics (1) Schémathèque Toute la Radio (STR) (No. 351)
Literature/Schematics (2) Radio Constructeur et Dépanneur (Correspondance Philips - Radiola, Juillet-Août 1956)
Literature/Schematics (3) -- Original prospect or advert (Le Journal, 21.09.1937)

Model page created by Peter Hoddow. See "Data change" for further contributors.
