471A; Philips Finland - (ID = 1349491) Radio
Philips Finland -: 471A [Radio] ID = 1349491 922x692
Select picture or schematic to display from thumbnails on the right and click for download.
For model 471A, Philips Finland - see also Fenno and TeRate

Country:  Finland
Manufacturer / Brand:  Philips Finland - see also Fenno and TeRate
Year: 1947 ? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: ECH21 ECH21 EBL21 AZ1 EM4
Main principle Superheterodyne (common)
Wave bands Broadcast, Long Wave and Short Wave.
Details
Power type and voltage Alternating Current supply (AC) / 110; 125; 145; 200; 220; 245 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 8 inch = 20.3 cm
Power out
from Radiomuseum.org Model: 471A - Philips Finland - see also
Material Wooden case
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 520 x 330 x 255 mm / 20.5 x 13 x 10 inch

Model page created by Timo Rantasaari. See "Data change" for further contributors.
