• Country
• Belgium

• Manufacturer / Brand
• Philips Belgium (Belgien)

• Year
• 1940/1941

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 257432

• Number of Tubes
• 5

• Valves / Tubes
• ECH3 EF9 CBL1 CY1 C1 or C9

• Main principle
• Superheterodyne (common); ZF/IF 128 kHz

• Tuned circuits
• 7 AM circuit(s)

• Wave bands
• Broadcast, Long Wave and Short Wave.

• Power type and voltage
• AC/DC-set / 110; 220 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Material
• Wooden case

• from Radiomuseum.org
• Model: 616L - Philips Belgium Belgien

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 430 x 300 x 210 mm / 16.9 x 11.8 x 8.3 inch

• Notes

• Urdox ballast tube: C1 (for 220 V), C9 (for 110 V).

• Author
• Model page created by Hugo Sneyers. See "Data change" for further contributors.
